ANSI/ASMI B16.5 High Hub Blinds Flanges - Stainless Steel ASTM A182 316L, 317L

Specifications Of High Hub Blinds Flange

Dimensions Of High Hub Blinds Flange

Weight Chart Of High Hub Blinds Flange

Price List Of High Hub Blinds Flange

ASTM A105 High Hub Blinds Flanges, Inconel 600 High Hub Blinds Flanges, UNS S31803 High Hub Blinds Flanges, ASTM A182 SS 304 High Hub Blinds Flanges, Inconel 600 High Hub Blinds Flanges Exporter, Hastelloy C276 High Hub Blinds Flanges, PED Approved High Hub Blinds Flanges, UNS S32760 High Hub Blinds Flanges Stockist

UNS S32750 High Hub Blinds Flanges Supplier, UNS S32760 High Hub Blinds Flanges, Alloy 20 High Hub Blinds Flanges Manufacturer, PED Approved High Hub Blinds Flanges Exporter, Inconel 625 High Hub Blinds Flanges Exporter, Inconel 625 High Hub Blinds Flanges,UNS S30400 High Hub Blinds Flanges

Specification - ASME B16.5 High Hub Blinds Flanges

Size:	1/2"NB TO 24"NB IN
Class:	150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS DIN Standard ND-6,10, 16, 25, 40 Etc.
Materials:	Monel : Grade: Monel 400, Monel K500, Monel R-405 Nickel : Grade: Nickel 200, Nickel 201 Inconel : Grade: Inconel 600, Inconel 601, Inconel 625, Inconel 718 Incoloy : Grade: Incoloy 800, Inconel 800H, 800HT Hastalloy : Grade: Hastalloy B2, Hastalloy B3, Hastalloy C22, Hastalloy C276, Hastalloy X Titanium : Grade: Gr1, Gr2, Gr3, Gr5, Gr7, Gr11 Stainless Steel : Grade: ASTM A182 F202, F304/304L/304H, F316/316L, F316H, F316TI, F310, F321, F904L Carbon Steel : Grade: ASTM A105/A105N, A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, A694 F42, F46, F48, F50, F52, F56, F60, F65, F70, A516.60, 65, 70 (Spectacle Blind Flange, Spacer Ring/Spade Flange), Steel RST37.2, C22.8 Duplex Steel: Grade: ASTM / ASME A/SA 182 UNS F44, F45, F51, F53, F55, F60, F61 Alloy Steel: Grade : ASTM A182 F1, F5, F9, F11, F22, F91
Value Added Service:	CNC Machine, Customized Flanges
Coating/Surface Treatment:	Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized

Dimension - ASME B16.5 High Hub Blinds Flanges

Size in Inches	Size in Millimeter	Outer Diameter (O.D.)	Thickness Of Flanges	Hub Outside Daimeter	Weld Neck Outside Daimeter	Length Of Welding Neck	RTJ RF Diameter	Height Of RTJ RF	PCD	RTJ Pitch Diameter	RTJ Deptd	RTJ Widtd	Bore
A	B	C	D	E	F	G	H	I	J	K	L
1/2	15	90	9.6	30	21.3	46	N/A	N/A	60.3	N/A	N/A	N/A
3/4	20	100	11.2	38	26.7	51	N/A	N/A	69.9	N/A	N/A	N/A
1	25	110	12.7	49	33.4	54	63.5	6.35	79.4	47.63	6.35	8.74
1 1/4	32	115	14.3	59	42.2	56	73	6.35	88.9	57.15	6.35	8.74
1 1/2	40	125	15.9	65	48.3	60	82.5	6.35	98.4	65.07	6.35	8.74
2	50	150	17.5	78	60.3	62	102	6.35	120.7	82.55	6.35	8.74
2 1/2	65	180	20.7	90	73	68	121	6.35	139.7	101.6	6.35	8.74
3	80	190	22.3	108	88.9	68	133	6.35	152.4	114.3	6.35	8.74
3 1/2	90	215	22.3	122	101.6	70	154	6.35	177.8	131.78	6.35	8.74
4	100	230	22.3	135	114.3	75	171	6.35	190.5	149.23	6.35	8.74
5	125	255	22.3	164	141.3	87	194	6.35	215.9	171.45	6.35	8.74
6	150	280	23.9	192	168.3	87	219	6.35	241.3	193.68	6.35	8.74
8	200	345	27	246	219.1	100	273	6.35	298.5	247.65	6.35	8.74
10	250	405	28.6	305	273	100	330	6.35	362	304.8	6.35	8.74
12	300	485	30.2	365	323.8	113	406	6.35	431.8	381	6.35	8.74
14	350	535	33.4	400	355.6	125	425	6.35	476.3	396.88	6.35	8.74
16	400	595	35	457	406.4	125	483	6.35	539.8	454.03	6.35	8.74
18	450	635	38.1	505	457.2	138	546	6.35	577.9	517.53	6.35	8.74
20	500	700	41.3	559	508	143	597	6.35	635	558.8	6.35	8.74
24	600	815	46.1	663	610	151	711	6.35	749.3	673.1	6.35	8.74

Weight Chart Of High Hub Blinds Flanges

Nominal Pipe Size	Diameter of Pipe		Flange I.D	No. of holes	Flange Dia	Thk of Flange	Dia of Bolt Circle	Dia of Bolt Holes	Approx.Weight
DN	ISO	DIN	D5	BN	D	b	K	d2	KG/PCS
10	-	14	14.5	4	90	16	60	14	0.7
	17.2	-	17.7	4	90	16	60	14	0.69
15	-	20	21	4	95	16	65	14	0.77
	21.3	-	22	4	95	16	65	14	0.77
20	-	25	26	4	105	18	75	14	1.06
	26.9	-	27.6	4	105	18	75	14	1.05
25	-	30	31	4	115	18	85	14	1.27
	33.7	-	34.4	4	115	18	85	14	1.25
32	-	38	39	4	140	18	100	18	1.86
	42.4	-	43.1	4	140	18	100	18	1.83
40	-	44.5	45.5	4	150	18	110	18	2.12
	48.3	-	49	4	150	18	110	18	2.09
50	-	57	58.1	4	165	20	125	18	2.78
	60.3	-	61.1	4	165	20	125	18	2.74
65	76.1	-	77.1	8	185	22	145	18	3.48
80	88.9	-	90.3	8	200	24	160	18	4.33
100	-	108	109.6	8	235	24	190	22	5.82
	114.3	-	115.9	8	235	24	190	22	5.61
125	-	133	134.8	8	270	26	220	26	7.91
	139.7	-	141.6	8	270	26	220	26	7.6
150	-	159	161.1	8	300	28	250	26	10.12
	168.3	-	170.5	8	300	28	250	26	9.58
175	193.7	-	196.1	12	350	32	295	30	14.45
200	219.1	-	221.8	12	375	34	320	30	16.9
250	-	267	270.2	12	450	38	385	33	27.28
	273	-	276.2	12	450	38	385	33	26.51
300	323.9	-	327.6	16	515	42	450	33	36.38
350	355.6	-	359.7	16	580	46	510	36	52.83
	-	368	372.2	16	580	46	510	36	50.24
400	406.4	-	411	16	660	50	585	39	74.71
	-	419	423.7	16	660	50	585	39	71.44
500	508	-	513.6	20	755	52	670	42	86.87
600	610	-	616.5	20	890	54	795	48	121.84
700	711	-	716	24	995	58	900	48	150.93
800	813	-	818	24	1140	64	1030	56	219.08
900	914	-	920	28	1250	70	1140	56	271.16
1000	1016	-	1022	28	1360	78	1250	56	344.95

Price List Of High Hub Blinds Flanges

Stainless Steel High Hub Blinds Flanges	USD $2.07 - $10.08 / Piece (FOB Price) on request
High Nickel Alloys High Hub Blinds Flanges	USD $8.12 - $20.22 / Piece (FOB Price) on request
Duplex & Super Duplex High Hub Blinds Flange	USD $10.22 - $35.52 / Piece (FOB Price) on request
Cupro Nickel High Hub Blinds Flanges	USD $5.21 - $10.50 / Piece (FOB Price) on request
Carbon Steel High Hub Blinds Flanges	USD $2.10 - $7.12 / Piece (FOB Price) on request

Marking and Packing

Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All pipes are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.

Wooden Boxes

Wooden Pallets

Shrink-Wrapped

Carton Boxes

Wooden Boxes

Quality Assurance

At JF Engineering Products LLP, all fasteners are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.

Testing

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Positive Material Identification - PMI Testing
Chemical Analysis - Spectro Analysis
Mechanical Testing Such as Tensile, Elongation, Reduction of Area
Micro Test
Macro Test
Hardness Test
Pitting Resistance Test
Intergranular Corrosion (IGC) Test
Flaring Test
Flattening Test
Hydrostatic Test
Hydrogen-Induced Cracking (HIC) Test, NACE TM0284
Sulfide Stress Corrosion Cracking (SSC), NACE TM 0177
Radiography Test
Dye Penetrant Test (DP Test)

SHIPPING POLICY

Delivery time and delivery dates are based on the "type and quantity" of steel ordered. Our sales team will provide a delivery schedule when quoting to you. On rare occasions the delivery schedule may change so please check with our sales department when placing any orders.

Orders will be sent out within 2-3 business days, and may take up to 5-10 business days in transit. If fastener is out of stock, orders may take up to 2-4 weeks to ship. JF Engineering Products LLP will notify buyer if this situation occurs.

Uses & Application

JF Engineering Products LLP take immensure pleasure in introducing itself as one of the leading Manufacturer & Exporter of high quality fasteners to meet the customer ultimate requirements in the fields of:

Construction

Bridges

Petrochemical Industry

Ship Building

Engineering

General Structural Purposes

Offshore and Onshore Services

Power Generation Industries

Food Processing Industries

Oil & Gas Industries

Sugar Industries
