ISO ReducIng Flanges for international standards Organisation that manufactures and approves various products. These products are made considering international and national standards. These flanges are made from high-quality materials and other robust materials. These ISO stands are commonly used for joining two or more pipes, valves, and pipes together.
ISO flanges are highly ductile and famous in various industries because of their high weldability and strength. The Iso flanges standard are commonly renowned for their excellent chemical composition, and these flanges are applicable in multiple applications.
ISO flanges are chemically proven and robust. These flanges are highly malleable, and they offer excellent lateral strength and stability. These flanges are also known for providing excellent resistance.
ISO flanges provide excellent resistance from various chemical and physical reactions. ISO BlInd Flanges deliver superior protection from corrosion, crevice corrosion, and stress cracking.
| Size: | 1/2"NB TO 24"NB IN |
| Class: | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS DIN Standard ND-6,10, 16, 25, 40 Etc. |
| Materials: | Monel : Grade: Monel 400, Monel K500, Monel R-405 Nickel : Grade: Nickel 200, Nickel 201 Inconel : Grade: Inconel 600, Inconel 601, Inconel 625, Inconel 718 Incoloy : Grade: Incoloy 800, Inconel 800H, 800HT Hastalloy : Grade: Hastalloy B2, Hastalloy B3, Hastalloy C22, Hastalloy C276, Hastalloy X Titanium : Grade: Gr1, Gr2, Gr3, Gr5, Gr7, Gr11 Stainless Steel : Grade: ASTM A182 F202, F304/304L/304H, F316/316L, F316H, F316TI, F310, F321, F904L Carbon Steel : Grade: ASTM A105/A105N, A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, A694 F42, F46, F48, F50, F52, F56, F60, F65, F70, A516.60, 65, 70 (Spectacle Blind Flange, Spacer Ring/Spade Flange), Steel RST37.2, C22.8 Duplex Steel: Grade: ASTM / ASME A/SA 182 UNS F44, F45, F51, F53, F55, F60, F61 Alloy Steel: Grade : ASTM A182 F1, F5, F9, F11, F22, F91 |
| Value Added Service: | CNC Machine, Customized Flanges |
| Coating/Surface Treatment: | Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized |
| Size Of Flanges | T | D1 | C | B | Hole | F | G |
| NW16CF | 7,6 | 34 | 27 | 4,4 / M4 | 6 | 21,5 | 18,3 |
| NW35CF | 12,7 | 70 | 58,7 | 6,7 / M6 | 6 | 48,35 | 41,9 |
| NW50CF | 15.8 | 85,6 | 72,4 | 8,4 / M8 | 8 | 61,8 | 55,6 |
| NW63CF | 17,5 | 113,5 | 92,1 | 8,4 / M8 | 8 | 82,55 | 77,2 |
| NW100CF | 19,9 | 151,6 | 130,3 | 8,4 / M8 | 16 | 120,7 | 115,3 |
| NW150CF | 22,3 | 202,4 | 181 | 8,4 / M8 | 20 | 171,5 | 166,1 |
| NW200CF | 24,6 | 253,2 | 231,8 | 8,4 / M8 | 24 | 222,35 | 216,9 |
| NW250CF | 26 | 306 | 284 | 8,4 / M8 | 32 | 273,2 | 267 |
| NW300CF | 28,4 | 355,6 | 325,4 | 10,5 / M10 | 30 | 313,5 | 307,3 |
| NW350CF | 28,5 | 419,1 | 388,9 | 10,5 / M10 | 36 | 376,9 | 370,7 |
| Flanges Standard | Flanges Class | Flanges Diameter | Flanges Bolt Circle Diameter | Flanges Number of Bolts | Flanges Bolt Size | Diameter of Bolt Hole |
|---|---|---|---|---|---|---|
| AS4087 Flanges | PN14 Flanges | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C Flanges | 95 | 67 | 4 | 13 | 14 |
| Table D Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table E Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table H Flanges | 114 | 83 | 4 | 16 | 17 | |
| Table J Flanges | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 Flanges | ANSI 150 Flanges | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ISO 7005 (DIN) Flange | PN6 Flanges | 80 | 55 | 4 | M10 | 11 |
| PN10 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN16 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN20 Flanges | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN40 Flanges | 95 | 65 | 4 | M12 | 14 |
Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All pipes are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.
At JF Engineering Products LLP, all fasteners are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.
Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report
Delivery time and delivery dates are based on the "type and quantity" of steel ordered. Our sales team will provide a delivery schedule when quoting to you. On rare occasions the delivery schedule may change so please check with our sales department when placing any orders.
Orders will be sent out within 2-3 business days, and may take up to 5-10 business days in transit. If fastener is out of stock, orders may take up to 2-4 weeks to ship. JF Engineering Products LLP will notify buyer if this situation occurs.
