Monel 400/K500 Flanges

Specifications Of Monel 400/K500 Flanges

Equivalent Grades of Monel 400/K500 Flanges

Chemical Composition of Monel 400/K500 Flanges

Mechanical Properties of Monel 400/K500 Flanges

Different Type Of Monel 400/K500 Flanges

Dimensions of Of Monel 400/K500 Flanges

Weight Chart Of Monel 400/K500 Flanges

Price List Of Monel 400/K500 Flanges

Monel K500 Lap Joint Flange, Din 2.4375 Socketweld Flange, Monel K500 Orifice Flange, UNS N04400 Slip On Flange, ASME SB564 Monel K500 Weld Neck Flange, ASTM B564 Monel 400 Reducing Flange, ASTM B564 Monel 400 Threaded Flange, Din 2.4375 Blind Flange, ASME SB564 Monel K500 Forge Flange, UNS N04400 SORF Flange, ASTM B564 Monel 400 Square Flange.

Monel K500 Lap Joint Flange Stockist, ASTM B564 Monel 400 Reducing Flange Exporter, UNS N04400 Slip On Flange Supplier, ASME SB564 Monel K500 Forge Flange Manufacturer, ASTM B564 Monel 400 Threaded Flange Exporter, ASME SB564 Monel K500 Weld Neck Flange Exporter, Din 2.4375 RTJ Flange Stockist, UNS N04400 Longweld Neck Flange Supplier.

Specifications Of Monel 400/K500 Flanges

Standards	ANSI/ASME B16.5, EN Flanges, BS 10, B16.47 Series A & B, EN-1092, ASME Flanges, BS Flanges, B16.48, DIN, DIN Flanges, GOST Flanges, ANSI Flanges, BS4504.
Size	1/2" (15 NB) to 48" (1200NB) DN10~DN5000
Pressure Rating	Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS
Production technique	Forged, Heat treated and machined
Special design	As per your drawing
	AS, ANSI, BS, DIN and JIS
	15 NB (1/2") to 200 NB (8")
	Equal and Reducing Configurations
Connect Type/ Flange Face Type	Ring Type Joint (RTJ), Small Tongue, Raised Face (RF), Lap-Joint Face (LJF), Small Male-Female (SMF), Flat Face (FF), Large Tongue & Groove, Large Male-Female (LMF).
Largest Bore Diameter Sizes	NPS ≤ 10
Minimum & Maximum Size	1/2" To 48"
Origin	Indian / Japan / Korean / West Europe / USA
JIS Standard	5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K
A182 Flange EN	6Bar 10Bar 16Bar 25Bar 40Bar
Test Certificates	EN 10204/3.1B
	Raw Materials Certificate
	100% Radiography Test Report
	Third Party Inspection Report, etc.
Application	Gas, Power, Chemical, Metallurgy, Petroleum, Shipbuilding, Construction etc.

Equivalent Grades of Monel 400/K500 Flanges

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Monel 400	2.4360	N04400	NW 4400	NA 13	МНЖМц 28-2,5-1,5	NU-30M	NiCu30Fe
Monel K500	2.4375	N05500	-	-	-	-	-

Chemical Composition of Monel 400/K500 Flanges

Grade	Ni	Fe	C	Mn	Si	Cu	Al	Ti	S
400	63.0- 70.00 max	2.50 max	0.3 max	2.00 max	0.50 max	Remainder	-	-	0.024 max
K500	63.0 min	05 - 2	0.25 max	1.5 max	0.5 max	27.0 - 33.0	2.3 - 3.15	0.35 - 0.85	0.010 max

Mechanical Properties of Monel 400/K500 Flanges

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Monel 400	8.8 g/cm3	1350 °C (2460 °F)	Psi – 80,000 , MPa – 550	Psi – 35,000 , MPa – 240	40 %
Monel K500	8.44 g/cm3	1350 °C (2460 °F)	Psi – 160000 , MPa – 1100	Psi – 115000 , MPa – 790	20 %

Different Type Of Monel 400/K500 Flanges

ASME SB564 Monel K500 Lap Joint Flanges

ASTM B564 Monel 400 Threaded Flanges

UNS N04400 Socket Weld Flanges

Din 2.4375 Long Weld Neck Flanges

ASME SB564 Monel K500 Weldo / Nipo Flanges

ASTM B564 Monel 400 Orifice Flanges

ASTM B564 Monel 400 Plate Flange

ASME SB564 Monel K500 Reducing Flanges

ASTM B564 Monel 400 Flat Flanges

ASME SB564 Monel K500 Insert Flanges

UNS N04400 Jacket Insert Flanges

Din 2.4375 Standard Insert Flanges

ASME SB564 Monel K500 Loose Flanges

ASTM B564 Monel 400 RTJ Flanges

ASME SB564 Monel K500 SWRF Flanges

ASTM B564 Monel 400 Expander Flanges

UNS N04400 Tongue & Groove Flanges

Dimensions Of Monel 400/K500 Flanges

Nom. Pipe Size	O	T	R	X	No./Dia. of Holes	Bolt Circle Dia.	L2	H	B2	L	B	r	L3	B3	D
1/2	3.5	0.44	1.38	1.19	4-0.62	2.38	1.88	0.84	0.62	0.62	0.88	0.12	0.62	0.9	0.38
3/4	3.88	0.5	1.69	1.5	4-0.62	2.75	2.06	1.05	0.82	0.62	1.09	0.12	0.62	1.11	0.44
1	4.25	0.56	2	1.94	4-0.62	3.12	2.19	1.32	1.05	0.69	1.36	0.12	0.69	1.38	0.5
1-1/4	4.62	0.62	2.5	2.31	4-0.62	3.5	2.25	1.66	1.38	0.81	1.7	0.19	0.81	1.72	0.56
1-1/2	5	0.68	2.88	2.56	4-0.62	3.88	2.44	1.9	1.61	0.88	1.95	0.25	0.88	1.97	0.62
2	6	0.75	3.62	3.06	4-0.75	4.75	2.5	2.38	2.07	1	2.44	0.31	1	2.46	0.69
2-1/2	7	0.88	4.12	3.56	4-0.75	5.5	2.75	2.88	2.47	1.12	2.94	0.31	1.12	2.97	0.75
3	7.5	0.94	5	4.25	4-0.75	6	2.75	3.5	3.07	1.19	3.57	0.38	1.19	3.6	0.81
3-1/2	8.5	0.94	5.5	4.81	8-0.75	7	2.81	4	3.55	1.25	4.07	0.38	1.25	4.1	0.88
4	9	0.94	6.19	5.31	8-0.75	7.5	3	4.5	4.03	1.31	4.57	0.44	1.31	4.6	0.94
5	10	0.94	7.31	6.44	8-0.88	8.5	3.5	5.56	5.05	1.44	5.66	0.44	1.44	5.69	0.94
6	11	1	8.5	7.56	8-0.88	9.5	3.5	6.63	6.07	1.56	6.72	0.5	1.56	6.75	1.06
8	13.5	1.12	10.62	9.69	8-0.88	11.75	4	8.63	7.98	1.75	8.72	0.5	1.75	8.75	1.25
10	16	1.19	12.75	12	12-1.00	14.25	4	10.75	10.02	1.94	10.88	0.5	1.94	10.92	1.31
12	19	1.25	15	14.38	12-1.00	17	4.5	12.75	12	2.19	12.88	0.5	2.19	12.92	1.56
14	21	1.38	16.25	15.75	12-1.12	18.75	5	14	13.25	2.25	14.14	0.5	3.12	14.18	1.63
16	23.5	1.44	18.5	18	16-1.12	21.25	5	16	15.25	2.5	16.16	0.5	3.44	16.19	1.75
18	25	1.56	21	19.88	16-1.25	22.75	5.5	18	17.25	2.69	18.18	0.5	3.81	18.2	1.94
20	27.5	1.69	23	22	20-1.25	25	5.69	20	19.25	2.88	20.2	0.5	4.06	20.25	2.13
22	29.5	1.81	25.25	24.25	20-1.38	27.25	5.88	22	21.25	3.13	22.22	0.5	4.25	22.25	2.38
24	32	1.88	27.25	26.12	20-1.38	29.5	6	24	23.25	3.25	24.25	0.5	4.38	24.25	2.5

Weight Chart Of Monel 400/K500 Flanges

Normal Sizes In inch	Dimension	Flanges Dimensional Sizes 1/2 inch. to 2 1/2 inch.
		Class 125 Class 150		Class 300		Class 400		Class 600		Class 900		Class 1500		Class 2500
		inch.	mm	inch.	millimeter	inch.	mm	inch.	mm	inch.	mm	inch.	mm	inch		mm
1/2	A	3 1/2	88.9	3 3/4	95.2	3 3/4	95.2	3 3/4	95.2	4 3/4	121	4 3/4	121	5 1/4	133.4
	b	7/16	11.1	9/16	14.3	9/16	14.3	9/16	14.3	7/8	22.2	7/8	22.2	1 3/16	30.2
	D2	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9
	D1	2 3/8	60.3	2 5/8	66.7	2 5/8	66.7	2 5/8	66.7	3 1/4	82.6	3 1/4	82.6	3 1/2	88.9
	n	4	4	4	4	4	4	4	4	4	4	4	-	4	44
	d	5/8	15.9	5/8	15.9	5/8	15.9	5/8	15.9	7/8	22.2	7/8	22.2	7/8	22.2
3/4	A	3 7/8	98.4	4 5/8	117.5	4 5/8	117.5	4 5/8	117.5	5 1/8	130	5 1/8	130	5 1/2	139.7
	b	1/2	12.7	5/8	15.9	5/8	15.9	5/8	15.9	1	25.4	1	25.4	1 1/4	31.8
	D2	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9
	D1	2 3/4	69.8	3 1/4	82.5	3 1/4	82.5	3 1/4	82.5	3 1/2	88.9	3 1/2	88.9	3 3/4	95.2
	n	4	4	4	4	4	4	4	4	4	4	4	-	4	44
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	7/8	22.2	7/8	22.2	7/8	22.2
1	A	4 1/4	108	4 7/8	123.8	4 7/8	123.8	4 7/8	123.8	5 7/8	149.2	5 7/8	149.2	6 1/4	159
	b	9/16	14.3	11/16	17.5	11/16	17.5	11/16	17.5	1 1/8	28.6	1 1/8	28.6	1 3/8	34.9
	D2	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8
	D1	3 1/8	79.4	3 1/2	88.9	3 1/2	88.9	3 1/2	88.9	4	102	4	102	4 1/4	108
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1	25.4
1 1/4	A	4 5/8	117.5	5 1/4	133.4	5 1/4	133.4	5 1/4	133.4	6 1/4	159	6 1/4	159	7 1/4	184.2
	b	5/8	15.9	3/4	19	13/16	20.6	13/16	20.6	1 1/8	28.6	1 1/8	28.6	1 1/2	38.1
	D2	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5
	D1	3 1/2	88.9	3 7/8	98.4	3 7/8	98.4	3 7/8	98.4	4 3/8	111	4 3/8	111	5 1/8	130
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1 1/8	28.6
1 1/2	A	5	127	6 1/8	155.6	6 1/8	155.6	6 1/8	155.6	7	177.8	7	177.8	8	203
	b	11/16	17.5	13/16	20.6	7/8	22.2	7/8	22.2	1 1/4	31.8	1 1/4	31.8	1 3/4	44.5
	D2	2 7/8	73 98	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73
	D1	3 7/8	4	4 1/2	114	4 1/2	114	4 1/2	114	4 7/8	124	4 7/8	124	5 3/4	146
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	. 15.9	7/8	22.2	7/8	22.2	7/8	22.2	1 1/8	28.6	1 1/8	28.6	1 1/4	31.8
2	A	6	152.4	6 1/2	165.1	6 1/2	165.1	6 1/2	165.1	8 1/2	215.9	8 1/2	215.9	9 1/4	234.9
	b	3/4	19	7/8	22.2	1	25.4	1	25.4	1 1/2	38.1	1 1/2	38.1	2	50.8
	D2	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1
	D1	4 3/4	121	5	127	5	127	5	127	6 1/2	165.1	6 1/2	165.1	6 3/4	171
	n	4	4	8	8	8	8	8	8	8	8	8	8	8	8
	d	3/4	19	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1 1/8	28.6
2 1/2	A	7	177.8	7 1/2	190.5	7 1/2	190.5	7 1/2	190.5	9 5/8	244	9 5/8	244	10 1/2	266.7
	b	7/8	22.2	1	25.4	1 1/8	28.6	1 1/8	28.6	1 5/8	41.3	1 5/8	41.3	2 1/4	57.2
	D2	4 1/8	104.8	4 1/8	104.8	4 1/8	104.8	4 1/8	104.8	4 1/8	105	4 1/8	105	4 1/8	105
	D1	5 1/2	139.7	5 7/8	149.2	5 7/8	149.2	5 7/8	149.2	7 1/2	190.5	7 1/2	190.5	7 3/4	197
	n	4	4	8	8	8	8	8	8	8	8	8	8	8	8
	d	3/4	19	7/8	22.2	7/8	22.2	7/8	22.2	1 1/8	28.6	1 1/8	28.6	1 1/4	31.8

Price List Of Monel 400/K500 Flanges

ASTM B564 Monel 400/K500 Slip On Flanges	USD $8.12 - $20.22 / Piece (FOB Price) on request
Monel 400/K500 Weld Neck Flanges	USD $8.12 - $20.22 / Piece (FOB Price) on request
Monel 400/K500 Lap Joint Flanges	USD $8.12 - $20.22 / Piece (FOB Price) on request
Monel 400/K500 Threaded Flanges	USD $8.12 - $20.22 / Piece (FOB Price) on request
UNS N04400/N05500 Socket Weld Flanges	USD $8.12 - $20.22 / Piece (FOB Price) on request

Marking and Packing

Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All pipes are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.

Wooden Boxes

Wooden Pallets

Shrink-Wrapped

Carton Boxes

Wooden Boxes

Quality Assurance

At JF Engineering Products LLP, all fasteners are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.

Testing

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Positive Material Identification - PMI Testing
Chemical Analysis - Spectro Analysis
Mechanical Testing Such as Tensile, Elongation, Reduction of Area
Micro Test
Macro Test
Hardness Test
Pitting Resistance Test
Intergranular Corrosion (IGC) Test
Flaring Test
Flattening Test
Hydrostatic Test
Hydrogen-Induced Cracking (HIC) Test, NACE TM0284
Sulfide Stress Corrosion Cracking (SSC), NACE TM 0177
Radiography Test
Dye Penetrant Test (DP Test)
